QUENCHANTS

The rapid development of modern heat treatment has put forward new requirements for quenchants.


PETROFER continues to conduct in-depth research and exploration, to conduct experimental research on a variety of new raw materials, to investigate the functions and effects in the trial, and compare the properties with our existing quenchants series, so that the practical advanced technology can be fully integrated into our products.


We work closely with customers to provide products suitable for the heat treatment process to improve production efficiency, reduce energy consumption, and bring profits to customers.


QUENCHANTS OILS


The ISORAPID quenching oil is suitable for all kinds of low carbon alloy steel and carbon steel and other materials with poor hardenability, as well as all kinds of thick and large cross-section workpiece quenching and cooling. The high viscosity quenching oil is suitable for the quenching cooling of thin-walled parts and a range of parts with stringent warping and deformation requirements. Normal speed quenching oil is suitable for quenching and cooling parts with good hardenability and high alloy content.

Model Range
ISOMAX 100/169 -Quenching for fastener;
-Quenching and tempering for die forging parts;
-Quenching for forging heat;
-Quenching for leaf spring and spiral spring.
Adaptive temperature:30-70℃,40℃viscosity:12.5/14.0mm?/s
Model 40℃viscosity Adaptive Temperature
ISORAPID 221 21mm?/s 50-80℃
ISORAPID 277/277 HM 24/25mm?/s 50-80℃
ISORAPID 455/459 50/49mm?/s 50-100℃
Application range: Suitable for closed furnace; carburizing steel, hardened and tempered steel, tool steel; the preferred product of contemporary heat treatment shop.
Model 40℃viscosity Adaptive Temperature
MARQUENCH 722/729 78/75mm?/s 60-150℃
MARQUENCH 849 156mm?/s 70-150℃
MARQUENCH 875 110mm?/s 70-160℃
Application range: Reduce the deformation of gear, shaft, ball bearing and roller bearing.



Model 40℃viscosity Adaptive Temperature
MARQUENCH 3500 480mm?/s 150-250℃
Application range: Seal oil use for circular saw blade, ring heating furnace and well type furnace.
Model 40℃viscosity Adaptive Temperature
VACUQUENCH B 244 28mm?/s 30-70℃
VACUQUENCH 305 30mm?/s 40-80℃
VACUQUENCH 605 55mm?/s 50-150℃
Application range: Special for vacuum equipment, according to the material hardenability to select the specific type.
Model 40℃viscosity Adaptive Temperature
ISODUR 220 19mm?/s 50-80℃
ISODUR 350 38mm?/s 60-90℃
MARQUENCH 600 58mm?/s 60-150℃
MARQUENCH 1400 260mm?/s 100-180℃
Application range: Lower cooling rates, depending on viscosity, applied to quenching of high alloy steels.
Model 40℃viscosity Adaptive Temperature
ISOMAX 150/170 13/12mm?/s 40-70℃
Application range: New series , based on GTL base oil technology;very short vapor film stage, high stability
Model 40℃viscosity Adaptive Temperature
ISORAPID 280 23mm?/s 50-80℃
Application range: New series , based on GTL base oil technology;very short vapor film stage, high stability.
Model 40℃viscosity Adaptive Temperature
VACUQUENCH B 255 28mm?/s 30-80℃
Application range: New series , based on GTL base oil technology;very short vapor film stage, high stability.

WATERMISCIBLE POLYMER


The polymer quenchant is fully integrated with water,when the hot workpiece is immersed into the quenching liquid, its surface will be surrounded by a layer of water-rich and high-concentration polymer stripping film with heat insulation (the thickness of this film mainly depends on the concentration of the quenching liquid). When the workpiece’s temperature drops to the temperature of the quenching liquid (normal temperature), the polymer stripping layer will be dissolved back into the quenching liquid. Therefore, the characteristics of polymer quenchant in the actual use of is with lower consumption and cost.

Model Quenching Characteristic
AQUATENSID BW-3 Very short vapor film stage, in the martensite formation interval (convection stage) slow quenching rate, prevent workpiece cracking.
AQUATENSID BW-3-FF



Application range: Spray quenching of component after induction heating or flame heating. Quenching for non-alloy steel (carbon steel, castings), low alloy steel, alloy steel open quenching groove.
Recommended concentration:3-8%



Model Quenching Characteristic
AQUATENSID BW Very short vapor film stage, in the martensite formation interval (convection stage) slow quenching rate, prevent workpiece cracking.
AQUATENSID BW-FF



Application range: Spray quenching of component after induction heating or flame heating. Quenching for non-alloy steel, alloy steel open quenching groove,solution treatment of aluminum alloy.
Recommended concentration:5-20%



Model Quenching Characteristic
AQUATENSID D Solution treatment of aluminum alloy,reduce deformation



Application range: Heat treatment of aluminum alloy in aviation industry and sheet and profile in automobile industry.
Recommended concentration:5-30%

Product Model Recommended Concentratio Quenching Characteristic
FEROQUENCH 2000 5-20% Very short vapor film stage, in the martensite formation interval slow quenching rate, prevent workpiece cracking.
FEROQUENCH AP-2 10-25%
FEROQUENCH HQ-RS 5-8%



Application range: Spray quenching of component after induction heating or flame heating. Replace the application of quenching oil in alloy steel and high alloy steel.

Product Model Quenching Characteristic
AQUACOOL VSL Very short vapor film stage, in the martensite formation interval slow quenching rate, prevent workpiece cracking.
AQUACOOL VSL-FF



Application range: Spray quenching of component after induction heating or flame heating. Replace the application of quenching oil in alloy steel and high alloy steel.
Recommended concentration:3-20%

SALT BATHS


Salt baths is suitable for a variety of heat treatment , the advantages are: high flexibility, wide range of temperature, short holding time. Special salts can be used for quenching, carburizing and tank cleaning.

Product Model Applicable Range

HS
hardening bath

Salt baths is used in structural steel, case-hardening steel, modulated steel, and high-speed steel during the preheating phase of quenching.
NEUTROSAL Salt regeneration treatment.

SINOXAL
high speed steel bath

High-speed steel in high temperature treatment, prevent decarbonization.

CARBOGEN
CARBORAPID
CARBOMAX
carburising bath

Salt stabilizer.

CARBOTECT

Solid carburizing,cyaniding.

AS
quenching salt

Nitrite-free and nitrite-containing high temperature salt, used for steel quenching, bainite treatment and tempering, can also be used for aluminum alloy solution annealing, according to different melting point .

GS
quenching salt

For high-speed steel, tool steel annealing.

SFS 500-E/SFS
blackening bath

After salt baths nitriding, obtain excellent properties of salt spray and wear resistance.

BLACKY NF
bumishing bath

The steel parts are polished in a polishing bath at a temperature of around 150, without nitrite works.

HEAT TRANSFER SALTS

Nitrite-free and nitrite-containing materials of rubber vulcanization and other heat transfer process,can be applied to different melting points.
CLEANING SALTS Special salt baths formula for non-ferrous metal surface cleaning.
